TP-Link ER7212PC Omada Gigabit VPN Router with PoE+ Ports and Controller AbilityPORT: 2× Gigabit SFP WAN/LAN Port, 1× Gigabit R Omada

Original price was: $622.42.Current price is: $327.00. (inc. of GST)

TP-Link Omada 3-in-1 Gigabit VPN Router

Availability: In stock SKU: ER7212PC Category:
Tp-link logo - myithub
Availability: In stock


A Future-Proof, Versatile, and Compact Router with PoE+ Ports and Controller Capability

3-in-1 Router, More Than A Router

The 3-in-1 ER7212PC presents a one-stop solution for home and small business networking.

With a single compact box, the gigabit VPN router ER7212PC offers the ability of PoE+ output and Omada centralised management. There is no need to manually configure various network devices one by one, you can perform unified deployment through ER7212PC. All you need is one device.

Up to Four WAN Gigabit Ports to Optimise Bandwidth Usage

Equipped with multiple ports, ER7212PC satisfies various internet access requirements through one device. The multi-WAN Load Balancing function distributes data streams according to the bandwidth proportion of every WAN port to raise the utilization rate of multi-line broadband.

Easy Installation, Quiet Heat Dissipation

A clean, well-organized, and quiet network environment is at your fingertips.

  • The compact and minimalist design makes it suitable for your configuration in various spaces, whether it’s the corner of office desks or the ceiling of a store.
  •   Fanless design offers noiseless heat dissipation to your shops or offices.

Embedded Omada SDN Controller

The built-in Omada SDN controller enables ER7212PC to manage and update your devices in bulk, with no need for individual and complex setup. Additionally, check the Omada app or web browser, ER7212PC allows you to remotely control connected devices, monitor the network, and view the network maintenance in real time.

High-Security and High-Performance VPN

ER7212PC supports pass-through traffic and multiple VPN protocols, including OpenVPN, IPSec, PPTP, and L2TP in Client/Server mode. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment.

What’s in it for you?

  • 3-in-1 Router: Integrates router, PoE+ output, and Omada centralized management ability altogether.
  • Professional Hardware: Dual-Core CPU with 1GB DDR3 memory provides stellar performance for up to 12× Gigabit ports.
  • Up to 4× WAN Ethernet Ports: Equipped with 2× Gigabit SFP WAN/LAN ports, 1× Gigabit RJ45 WAN port, and 1× Gigabit RJ45 WAN/LAN port.
  • 110W PoE Budget: 8× 802.3at/af-compliant PoE+ RJ45 LAN ports yield a total power supply of 110W*.
  • Centralised Management: Cloud access and the Omada app offer convenience and easy management.
  • Highly Secure VPN: Supports IPsec VPN, OpenVPN, and L2TP/PPTP VPN connections.
  • Easy Installation: Fanless and compact design for desktop and wall mounting.
Ports & interfaces
  • Ethernet LAN (RJ-45) ports: 10
  • Power over Ethernet (PoE) ports quantity: 8
  • Combo SFP ports quantity: 2
  • DC-in jack: ✔
Weight & dimensions
  • Width: 226 mm
  • Depth: 131 mm
  • Height: 35 mm
  • Output voltage: 53.5 V
  • Output current: 2,43 A
  • Power over Ethernet (PoE): ✔
Operational conditions
  • Operating temperature (T-T): 0 - 45 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%
  • DHCP client: ✔
  • DHCP server: ✔
  • Supported protocols: TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, SNMP
  • Networking standards: IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
  • Ethernet interface type: Gigabit Ethernet
  • Cabling technology: 10/100/1000Base-T(X)
  • Ethernet LAN data rates: 10,100,1000 Mbit/s
  • Static route: ✔
  • VLAN support: ✔
  • Port forwarding: ✔
Packaging data
  • AC adapter included: ✔
  • Manual: ✔
  • URL filtering: ✔
  • Access Control List (ACL): ✔
  • NAT functionality: Multi-Net NAT; Virtual Server; NAT-DMZ; FTP/H.323/SIP/IPSec/PPTP ALG; UPnP;
Management features
  • Universal Plug and Play (UPnP): ✔
  • Reset button: ✔
  • Product colour: Black
  • Housing material: Metal
  • LED indicators: ✔
  • Built-in processor: ✔
  • Processor frequency: 1200 MHz
  • Flash memory: 4096 MB
  • Internal memory: 1024 MB
  • Internal memory type: DDR3
  • Certification: CE, FCC, RoHS
WAN connection
  • Ethernet WAN: ✔
  • DSL WAN: ❌
  • SIM card slot: ❌
  • 3G/4G USB modem compatibility: ❌
  • SFP WAN: ✔
