D-Link DGS-1100-24PV2 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Original price was: $802.95.Current price is: $484.00. (inc. of GST)

24-Port Gigabit Smart Managed PoE Switch with 12 PoE+ Ports (100W PoE budget), designed for SMB’s who expect a lot of their network, including support for surveillance and VoIP.

Availability: In stock SKU: DGS-1100-24PV2 Category:
D-link - myithub
Availability: In stock

Description

Managing your network just got easier with the D-Link DGS-1100-26MPV2. This smart switch offers an intuitive web user interface that simplifies the control of Layer 2 features, including VLANs, Spanning Tree Protocol (STP), and static link aggregation. With robust security features like IGMP snooping, Static MAC, and Storm Control, the DGS-1100 Smart family is the versatile solution you need for hassle-free networking.

Easy Deployment and Configuration

D-Link makes network management a breeze. Our free Network Assistant (DNA) tool displays all connected devices, expediting initial configuration. For advanced management, the free D-View 7 Network Management System provides full access to management tools, complete with a license for 25 nodes and 2 probes. Should you need to expand your network further, optional upgrade licenses are available.

Power Over Ethernet (PoE) for Large Deployments

The DGS-1100-26MPV2 is your solution for powering extensive deployments of VoIP phones, wireless access points, and network cameras. With a robust PoE budget of up to 370W, you can trust that your devices will stay powered and connected.

Simplified Troubleshooting

Network issues are no match for the DGS-1100-26MPV2. It features Loopback Detection to identify and automatically shut down ports causing network loops. The Cable Diagnostics tool allows network administrators to assess cable quality, recognize cable types, and detect errors quickly. Troubleshooting has never been this easy.

Green Technology for Energy Efficiency

We care about the environment and your energy bills. D-Link Green technology ensures the DGS-1100-26MPV2 operates efficiently and silently. Most of the family utilizes a fanless design for quiet, energy-efficient operation.

Surveillance Mode for Secure Video Management

The DGS-1100-26MPV2’s Surveillance Mode is your ally in managing security devices effortlessly. This feature automatically identifies your security devices and places them in a dedicated Auto Surveillance VLAN. With Surveillance Mode, video surveillance traffic is handled securely and efficiently, enhancing network security.

Upgrade your network management with the D-Link DGS-1100-26MPV2. Enjoy an easy-to-use web interface, robust PoE capabilities, simplified troubleshooting, and eco-friendly operation. Make your network work for you, not the other way around.

What’s in it for you?

  • 12 x 10/100/1000BASE-T PoE+ ports
  • 12 x 10/100/1000BASE-T ports
  • PoE+ support with up to 30W per port
  • 100 Watts PoE Power Budget
  • Bandwidth Control ensures latency-sensitive traffic always gets the bandwidth it needs
  • Quality of Service further prioritizes latency-sensitive traffic, ensuring timely delivery
  • Segregate different types of traffic, such as surveillance or voice, with VLANs to heighten security
  • IGMP Snooping sends multicast traffic only where it needs to go, significantly cutting down network traffic
  • Innovative energy saving features are good for your budget, as well as the environment
  • Get up and going quickly with streamlined first-time setup and ongoing management
Ports & interfaces
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Weight & dimensions
  • Width: 280 mm
  • Depth: 230 mm
  • Height: 44 mm
  • Weight: 2,2 kg
Power
  • AC input voltage: 100 - 240 V
  • Power consumption (max): 19,5 W
Operational conditions
  • Operating temperature (T-T): -5 - 50 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 0 - 95%
  • Storage relative humidity (H-H): 0 - 95%
  • Operating altitude: 0 - 2000 m
  • Heat dissipation: 107,5 BTU/h
Network
  • Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
  • 10G support: ❌
  • Copper ethernet cabling technology: 10BASE-T, 10BASE-TX, 1000BASE-T
  • Port mirroring: ✔
  • Full duplex: ✔
  • Flow control support: ✔
  • Link aggregation: ✔
  • Broadcast storm control: ✔
  • Rate limiting: ✔
  • Auto MDI/MDI-X: ✔
  • Spanning tree protocol: ✔
  • Head-of-line (HOL) blocking: ✔
  • Auto-negotiation: ✔
  • VLAN support: ✔
  • Virtual LAN features: Port-based VLAN, Voice VLAN
  • Number of VLANs: 128
Data transmission
  • MAC address table: 8000 entries
  • Switching capacity: 48 Gbit/s
  • Forwarding rate: 35,71 Mpps
  • Store-and-forward: ✔
  • Number of queues: 4
  • Jumbo frames support: ✔
  • Jumbo frames: 9216
  • Packet buffer memory: 4,1 MB
Security
  • DHCP features: DHCP client
  • IGMP snooping: ✔
  • Security algorithms: SNMP, SSL/TLS
  • Queue scheduling algorithms: SPQ, Weighted Round Robin (WRR)
Management features
  • Switch type: Managed
  • Switch layer: L2
  • Quality of Service (QoS) support: ✔
  • Web-based management: ✔
  • System event log: ✔
Design
  • Rack mounting: ✔
  • Product colour: Black
  • LED indicators: ✔
  • Certification: EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC
Power over Ethernet (PoE)
  • Power over Ethernet (PoE): ✔
  • Power over Ethernet plus (PoE+) ports quantity: 12
  • Power over Ethernet (PoE) power per port: 30 W
  • Total Power over Ethernet (PoE) budget: 100 W
Performance
  • Built-in processor: ✔
  • Processor frequency: 125 MHz
  • Memory type: DRAM
  • Flash memory: 16 MB
  • Fanless: ✔
  • Mean time between failures (MTBF): 255003 h
Logistics data
  • Harmonized System (HS) code: 85176990
Multicast features
  • Multicast support: ✔
